Apple interested in putting Touch ID sensor directly into touchscreen displays

Adam Westlake - Feb 8, 2015, 10:00 am CST
16
Apple interested in putting Touch ID sensor directly into touchscreen displays

One of the largest ongoing critiques against the iPhone has been the fairly large bezels above and below the display. With Apple‘s flagship mobile device still sporting a circular home button, there’s been little to shave off and maintain the iPhone’s symmetric look. If Apple ever does decide to reduce, or eliminate, the home button, there would be nowhere to put the Touch ID fingerprint sensor, right? Maybe not, as a recent patent discovery hints that Apple may one day implement the sensor directly into its touchscreens.

Among the details in the patent titled “Fingerprint Sensor in an Electronic Device,” published last week by the US Patent and Trademark Office, are how a touchscreen-based Touch ID would be designed to scan a single fingerprint at a specific location on the display. So when it came time to unlock their device, or use a Touch ID-based feature, for example buying a song on iTunes, users would place their thumb or finger on that part of the screen for authentication.

Apple interested in putting Touch ID sensor directly into touchscreen displays

Apple’s proposed invention also mentions the ability to have a fingerprint be scanned from any single location on the screen, or even scan multiple fingers at once. Imagine when it comes time to use a Touch ID feature on an iPhone and simply placing a thumb anywhere on the screen that is comfortable. Or, in the case of an iPad, having all five fingerprints scanned by placing one’s hand on the screen.

Apple interested in putting Touch ID sensor directly into touchscreen displays

It seems the primary concern with embedding fingerprint sensors into touchscreen displays is that doing so comes at a cost to image quality, or a reduction in sensitivity to touch inputs. Apple’s solution suggests making the fingerprint sensor an integrated circuit connected either to the top or bottom surface of the display. As for the reduction in touch sensitivity, Apple thinks a full-panel fingerprint sensor could also be used for detecting touch inputs, in other words having the technology both detecting touch and scanning fingerprints.

VIA Apple Insider
SOURCE US Patent and Trademark Office
